Camera Module OV7670

Product description

Color: Black + blue;
Material: Glass fiber + plastic + iron

Features
Photosensitive Array: 640 x 480;
IO Voltage: 2.5V to 3.0V;
Operating Power: 60mW/15fpsVGAYUV;
Sleeping Mode: <20 uA;
Operating Temperature: -30 to 70 deg C.;
Output Format: YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data (8 digit);
Lens Size: 1/6";
Vision Angle: 25 degree;
Max. Frame Rate: 30fps VGA;
Sensitivity: 1.3V / (Lux-sec);
Signal to Noise Ratio: 46 dB;
Dynamic Range: 52 dB;
Browse Mode: By row;
Electronic Exposure: 1 to 510 row;
Pixel Coverage: 3.6um x 3.6um;
Duck Current: 12 mV/s at 6'C
